Core

Processor —Qualcomm Quad-Core 1.1GHz Processor

Graphic — Adreno 304

RAM — 2GB

ROM — 16GB Flash

OS — Android 7.1.2

Display

LCD Panel — 7” LED Backlit

Resolutions — 1280x800

Brightness — Up to 500nits (Sunlight Readable)

Contrast Ratio — 800:1

View Angle — 178°/178° (H/V)

Touch Panel — Capacitive

Wireless

WiFi — 802.11a/b/g/n 2.4GHz & 5GHz

Bluetooth — 4.0 2402MHz~2480MHz

Cellular — 4G/3G

GNSS

GPS — 1575.42MHz ±1.023MHz

GLONASS — 1597.5MHz-1605.8MHz

Camera

Front Camera — 2.0MP

Rear Camera — 5.0MP

Rich Interface

USB OTG — High Speed Up to 480Mbps

Micro SD Card — 1.8V / 2.95V, Up to 64G

SIM Card — 1.8V / 2.95V

ACC — 8-30V

GPIO — 0-5V Input, 0-3.7V Output

RS232 — COM1, COM2

RJ45 — 100Mbps

Mounting

Docking Station

• Handheld
• Fixed

Bracket Support

• 75mm VESA
• RAM Mounting

Power Supply

DC In — 10-36V

Battery — Built-In 3.7V, 5000mAh

Mechanical

Dimensions: 199.4 x 125.6 x 17.5 (mm)

Weight: 465g
