LCD Panel

LCD Size — 8-inch IPS

Backlight — LED

Resolution — 1920 x 1200

Brightness — 550 nits

Touch Glass — 5-Point Capacitive Multi Touch Screen, 7H Tempered Glass, G+G

Camera — Front 5.0MP; Rear 8.0MP

System

CPU — Intel Alder LAKE N100

Memory — 8GB LPDDR5

Storage — 128GB EMMC

Wi-Fi — Module Intel AX101 (1216 1x1)

Interfaces

• 1x USB-A 3.0
• 1x USB-C 3.0 (Data & Charging)
• 1x HDMI 2.0 Mini
• 1x TF Card
• 1x SIM Card
• 1x 3.5mm Earphone Jack
• 1x 12 PIN Pogo Pin

Buttons

• Power (Yellow)
• Volume + Key
• Volume - Key
• P1 Key (HOME Key)
• Function Key (Barcode Scanning, Connected to GPIO)

Connectivity

• WIFI 6 802.11(a/b/g/n/acR2/ax 1x1) Frequency: 2.4G + 5.8G Dual-Band Bluetooth 5.2 (BLE)
• 5G: NR SA: n1/ 2/ 3/ 5/ 7/ 8/ 12/ 13/ 14/ 18/ 20/ 25/ 26/ 28/ 30/ 38/ 40/41/ 48/ 66/ 70/ 71/ 77/ 78/79
• 4G LTE LTE FDD: B1/B2/B3/B4/B5/B7/B8/B12/B13/B14/B17/B18/B19/B20/B25/B26/B28/B30/B66/B70/B71
• 4G LTE LTE-TDD: B34/B38/B39/B40/B41/B42/B43/B48

GNSS — Supports GPS/GLONASS

NFC Optional

• NXP300/NFC 13.56MHz Supports
• 14443A/14443B/15693/18092/mifare protocols of ISO/IEC

2D Scanner (Optional)

• Optical Resolution: 5mil
• Scanning Speed: 50 Times/s
• Supported Barcode Types: PDF417, MicroPDF417, Data Matrix, Data
• Matrix Inverse Maxi Code, QR Code, Micro QR, QR Inverse, Aztec

Speaker — 2x Built in 8Ω/1W Waterproof Speaker

Microphone — Sensitivity: -42db, Output Impedance 2.2kΩ

OS — Windows 11 Pro

Battery — 5000mAh, Removable Polymer Lithium-Ion Battery

RTC — 3V 1mAH Rechargeable Surface-Mount

G-Sensor — Support

Power — DC12V / 4A (Male Plug Outer Diameter 5.5mm)

Machanical

Color — Black

Form Factor — 236.7 x 155.9 x 20.8 mm (W x L x H)

Weight — 818g

Material — Polycarbonate (PC) & Thermoplastic Polyurethane (TPU)
