CPU

Intel® Core i7-1355U Processor, 12M Cache, up to 5.00 GHz

Memory

2x SO-DIMM, DDR4 Max Support 64GB

Storage

2x SATA III, 6Gb/s

1 x M.2 M Key, Support M.2 2280mm SATA and NVME PCIe SSD

Display

Intel® Integrated Graphics Triple Display

2*HDMI Max. 4096x2304@60Hz

1*VGA Max. 1920 x 1200 @ 60Hz

Ethernet

2 x RTL8111H 10/100/1000 Gigabit Ethernet

I/O

2 x RJ45

2 x HDMI

1 x VGA

2 x USB3.2, 6 x USB2.0

1 x LINE-OUT &MIC-IN

Realtek ALC897 HD Audio Decoding Controller

2 x COM DB9

COM1, COM2 Support RS485/RS232 SET(Default Setting: RS232)

COM1, COM2 Support Pin9 +5V/+12V/RI SET

1 x Power Button

1 x Power LED; 1x HDD LED

2 x Antenna Mounting Hole

1 x DC Jack

Expansion (WIFI/GPS)

1 x M.2 E-Key (For Wi-Fi 6+ Bluetooth or WWAN+GNSS)

1 x M.2 B-Key (For WWAN+GNSS)

Power Input

DC IN +12 to 19V（φ5.5/2.5mm)

Other

TPM2.0,

Watchdog H/W Reset: 1Sec. ~ 65535 Sec./Min. and 1 Sec. or 1Min./Step.

OS

Windows 11 Pro

Form Factor

193.7 x 228 x 51 mm

Weight

Approx. 2.0 kg

Mounting

Standard Floor Mount
