CPU

Qualcomm® QCM6690, Octa-core, up to 2.9 GHz

LCD Panel

10.1” FHD IPS LCD, 1200 x 1920

Brightness

1000 nits (optional: 700 nits and 1300 nits)

Memory

8GB (optional: 16GB)

Storage

128GB (optional: 256GB)

OS

Andriod 16, GMS

Camera

Front: 8MP FF

Rear: 13MP PDAF

Battery

3.85V, 10200mAh

Cellular / WWAN

5G NR: FDD n1/n2/n3/n5/n7/n8/n20/n28; TDD n38/n40/n41/n77/n78/n79

4G LTE: FDD B1/B2/B3/B4/B5/B7/B8/B20/B26/B28; TDD

B38/B39/B40/B41/B42/B43

WCDMA: B1/B2/B5/B8

GSM: B2/B3/B5/B8

MIMO: 4G LTE up to 4×4 MIMO (DL); 5G NR up to 4×4 MIMO (DL) and 2×2

MIMO (UL)

Wireless

Wi-Fi 6E, IEEE 802.11 a/b/g/n/ac/ax, Tri-band 2.4 GHz / 5 GHz / 6 GHz,

Bluetooth 5.2, GPS

Speaker

Dual speakers, 1W / 8Ω, IP68-rated waterproof speakers

Speaker

2x 1W Speaker

Sensor

G-sensor, Accelerometer, Ambient Light Sensor, Proximity Sensor,

Sensor

Gravity sensor, Light sensor, Range sensor, Gyroscope sensor

Gyroscope, Digital Compass

Touch

10-point capacitive multi-touch, 7H hardness

Interface

1x USB3.0 Type-C (OTG, audio input/output, and charging)

1x TF Card, support Micro SD card up to 1TB

1x SIM Card, dual SIM (Nano & Nano)

Power

Input: 100~240VAC, Output: 18W

Touch

Capacitive Touch, including Capacitive Touch Pen

NFC

Support

Fingerprint

Optional

1D/2D Scan

Optional

I/O Interface

1x USB3.0 Type-C, support OTG

1x USB2.0

1x HDMI1.4

1x RJ45, 1GbE

1x RS-232

1x 3.5mm Headphone Jack

1x 12-pin Pogo Connector, support USB and Charging

1x Micro SIM Card Slot

1x TF Card, support up to 256GB

1x DC IN

Button

1x Power key, Volume + / Volume –, 2x programmable function keys (F key

/ P key)

Power

DC 5V/3A

Dimension

283.19 x 187.79 x 22.85 mm

Weight

Support

Uncalibrated Magnetometer

Support
