Basic Parameter

Form Factor — 274.9 x 188.7 x 22.2mm

Weight — 1020g

Device Color — Black

LCD — 10.1” FHD 16:10

Resolution — 1200x1920

Brightness — 1000 nits

Touch Panel — 10-Point Capacitive Touchscreen, Tempered Glass, G+G, Hardness: 7H

 Camera

• Front 5.0MP
• Rear 13.0MP Supports Autofocus, with Flashlight

Buttons

• Power x 1 (Yellow)
• Volume + Key x 1
• Volume - Key x 1
• P1 Key x 1 (HOME Key)
• F Key x 1 (Barcode Scanning)

I/O

• USB 3.0 Type-A x 1
• Type-C (Data & Charging) x 1,
• Nano-SIM x 2/Micro SD Supports Up To 512GB x 1
• Nano-SIM x 1 (Three-In-One Card Slot)
• RJ45 x 1
• HDMI x 1
• 12 PIN Pogo Pin x 1
• Φ3.5mm Standard Earphone Jack x 1
• DC Supports 5V/4A Charging x 1

Power  — Power Input 100-240VAC0.5A50/60Hz, DC Output 5V/4A

Speaker — Built in 8Ω/1W Waterproof Speaker x 2

Microphone — Sensitivity: -42db, Output Impedance 2.2kΩ

Sensors — G-Sensor, Light Sensor, Gyroscope, Compass

Fingerprint — Black Anodized Metal Frame, Dimensions: 34.75(L) x 29.77(W), Matte Black Finish

Communication

WiFi — Wi-Fi 6E & DBS, IEEE 802.11a/ b/ g/ n/ ac/ ax, Wi-Fi 2 × 2 MU-MIMO

Bluetooth — BTS5.2 (BLE)

2G/3G/4G/5G — 5G:SA/ NSA: n1/ 3/ 5/ 7/ 8/ 20/ 28/ 38/ 40/ 41/ 77/ 78/79

4G: B1/ 2/ 3/ 4/ 5/ 7/ 8/ 12/ 17/ 18/ 19/ 20/26/ 28/ 32/ 34/ 38/ 39/ 40/ 41/ 42

3G: B1/ 2/ 4/ 5/ 6/ 8/ 19

2G: B2/ 3/ 5/ 8

GNSS — Supports: GPS/GLONASS/BDS; Dual-Frequency L1 + L5

Performance Parameters

CPU — Octa-Core 2.7G ARM

OS — Android 14/GMS

RAM — 8GB LPDDR4x

ROM — 128GB EMMC

Battery

Capacity — 3.8V/10000mAh

Type — Removable Polymer Lithium-ion Battery

Endurance — 6 Hrs (Default 50% Volume, Connected to WiFi, Default 200 nits Brightness, Playing 1080P HD Video)

RTC — Built-In Rechargeable 3V/1mAh Lithium-ion Battery

Data Collection

NFC

• Built-In, 13.56MHz
• Supports 14443A/14443B/15693 of ISO/IEC
• Card Reading Distance: 0-4 cm

2D

• Optional, Optical Resolution: 5 mil
• Scanning Speed: 50 Times/s

Certification

IP65

CE NB

FCC (Optional)

CCC (Optional)

MIL-STD-810H

CEC

Battery: UN38.3, MSDS, Aviation and Maritime Report, IEC62133
