LCD Panel

LCD Size — 15.6 inch LCD Screen

Backlight — WLED

Resolution — 1920 x 1080

No. of Colour — 16.2M 73%NTSC

Viewing Angle — 85/85/85/85(Typ.)(CR≥10)

Luminance — 1000nits (after Bonding)

Contrast Ratio — 800:1

Pixel Pitch — 0.17925×0.17925mm(H×V) [141PPI]

Aspect Ratio — 16:9

LCD Panel Life Time — 50000 hrs

Interface — LVDS

Response Time — 13/12(Typ.)(Tr/Td)ms

Active Area — 344.16(W) x 193.59(H) mm

Light Sensor — Support Brightness Adjustment

Touch Glass

Touchscreen — Capacitive Touchscreen with Runtime Touch Sensitivity Control (Linux-Compatible)

Touch Support —

• Support Switching/Tuning Touch Modes
• Support Rain Mode, Glove Mode (Max Thickness: 2mm)

Optical Bonding — Support

Cover Glass — Surface Antiglare Glass

Glass Surface Hardness —  Hard Coating (3H)

Interfaces

Power Input — Wide Range 9~36V (via Industrial Screw Terminal)

Input Sources —

• 1x HDMI
• 1x DVI
• 1x USB

OSD Keypad — N/A

OSD Keys — N/A

Mechanical

Material — Aluminium Alloy

Coating —  UV Resistant Coating

Design —  Front Mounted

Form Factor —  Approx. 566 x 362 x 50mm
