LCD Size

32-inch LCD

Brightness

2,500 cd/㎡, with Auto Ambient Light Sensor

Resolution

1920 x 1080 Full HD

Contrast Ratio

1200:1

Viewing Angle

178° (H) / 178° (V)

Aspect Ratio

16:9

Display Area

717 x 412 mm

Backlight

LED, Sunlight-Readable, Ambient Light Sensor Control

Glass Protection

4mm Tempered Explosion-Proof Glass

Service Life

Over 50,000 Hours (24/7 Continuous Operation)

CPU

MTK YS-E9679, ARM Quad-Core Cortex-A73, up to 1.4GHz

GPU

Mali-G52

Memory

DDR4 4GB (Optional 8GB)

Storage

eMMC 32GB (Optional 128GB) + External SSD 256GB

OS

Android 11.0+

Expansion

USB2.0 x3, USB3.0 x2 (Can be Storge Expansion), Type-C x1

Audio

8Ω 5W x2 Speaker Output, Optional MIC, Headphone Jack

Video Interface

HDMI 2.0 or LVDS/eDP

Power

220V

Cooling System

Integrated Smart Fan, Auto Temperature-sensing Speed Control

IP Rating

IP65

Communication

Wifi, 2.4G/5G

Bluetooth

5.0

Lighting Protection

Class C Lightning Protection Device

Anti-UV/Glare

Anti-UV, Automatic Brightness Adjustment, Night-Time Energy-Saving Mode

Coating

Inner: Zinc-rich Primer / Outer: Outdoor-Grade Powder Coating

Mounting Type

Side-Mounted to Lamp Pole (Internal Fixed)
