RJ45 (10/100/1000M)
48
SFP (100/1000M)
N/A
Combo 1G Port
4(SFP)
SFP+ 10G
2
10G Extension Card (SFP+*2)
1
Console (RS232)
DB9
Backplane Bandwidth
176 Gbps
Real Time Preview
Yes
Up-Port Transfer Control
Yes
Extension List
Yes
LLDP (Connected Devices)
Yes
IGMP Snooping
Yes
SNMP Setting
Yes
RSTP Port Status
Yes
Transfer Volume Monitor and Analysis
Yes
Network Cable Distance Detection
Yes
CLI (Third Part Control)
RS232 / Telnet / HTTP
Manage Mode
RS232 / Telnet / HTTP
Dimension (mm)
442 x 300 x 44
Weight
4.2kg
Power
100-240 VAC
50~60 Hz
