Video

Max. Resolution

• 3840x2160P30 (HDMI)
• 1920x1200P60 (DVI/ VGA)

VGA input — Yes

VGA Output — N/A

HDMI — HDMI 2.0a Input (Compatible DVI-D)

3D Format — HDMI 1.4b 3D: TnB, SbS, F.P

Colour Depth — 1080p: 24, 30, 36 bpp – 2160p: 24bpp

HDR — Yes

HDCP 1.4 — Yes

HDCP 2.2 — Optional

EDID — Built-in EDID Simulator, Support Display EDID or Customized EDID

Latency (Tx → Rx, Typ.) — 1 Frame (About 33ms)

Compression — Visual Lossless (Compressed Transfer)

Display Input/Output Mix — Support HDMI-in to VGA Out, and VGA-in to HDMI-out

Scaler — Yes (Upscaling/ Downscaling 2x)

Picture Preview — Yes (Support BMP, PNG, JPG)

Audio

HDMI Format — 2ch and 8ch LPCM, 5.1ch and 7.1ch NLPCM (Dolby TrueHD, DTS-HD, Dolby Atmos, DTS:X)

Port — 3.5mm (Stereo)

Two-Way Transmission — Analog, Under UNICAST Mode

Digital & Analog Switch — Yes (Analog → HDMI, or HDMI → Analog)

USB Interface

Max. USB Ports — 5

Support Devices — USB Input/ Output Devices, Card Reader, Storage, Etc.

KVM — Support, OSD Menu, Hot Key, Multi Rx to 1Tx Control

Mouse Roaming — Support, Cross-Platform

Authorization Control — Support, USB Type, KVM Control (Optional)

IR

Frequency — 30K To 50K

Operation — Two-Way, Half-Duplex

GPIO

Out — 2 (0-3.3V)

In — 1 (0-3.3V)

RS232

Speed Rate — 300 to 115200 bps

Work Mode — Virtual, TCP/UDP Server, Uni-Mode, Broadcast Mode

Operation — Two-Way, Full-Duplex

Transmission

Standard — TCP/IP

Network — 1G/RJ45 (Suggest CAT5E, CAT6, CAT7 Cable)(POE Optional)

Fiber (Optional) — SFP + Support Single/ Multimode, Single/ Duplex LC

Redundancy — Yes, Electro-Optical Switching

Other Specs

Power — DC 5-19V/8W (Without USB & Module Power Supply)

Module Power Out — 5V/500mA

Size — 220 x 102 x 30 mm

Weight: 540g (Standard)
