LCD

LCD Size — 24-inch TFT

Backlight — LED

Resolution — 1920 x 1200

Interface — LVDS

View Angle — ± 89° (H), ±89° (V)

Luminance — 450 nits (after Bonding)

Contrast Ratio — 1000:1

Aspect Ratio — 16:10

Response Time — 14 ms (Typ.)

No. of Colour — 16.7 Million (8 Bit/Colour)

Active Area — 518.4 (H) x 324 (V) mm

Pixel Pitch — 0.27 (H) x 0.27 (V) mm

LED Life Time — 50,000 hrs

Supported Resolution — Up to 2560 x 1600 @60Hz Panel

Input Interface (Border Line) — 1x VGA, 1x DVI-D, 2x HDMI, 1x Audio, 1x USB for Touch

Input Interface (On Board Housing) — Backlight, STB (5V, 1amp), Light Sensor, Key + IR, RS232/485 (Reserved, Optional), Audio, Display Port (Reserved, Optional)

Output Interface — 1 x LVDS (40 Pins)

Others — 1x USB-A (By-Pass)

Audio — 10W+10W @ 8Ω Class-D Stereo Audio Amplifier

Power Input — DC+12V/ 24V (9-26 Available) Max. Current: 3amp; Quiescent Current

<50mA

Backlight Power Output — **By-Pass from DC Jack Power Input (Needs to Make Sure the

Power Input = Backlight Power Required)

Backlight Max Current — 6amp

LVDS Power Selection — DC+3.3V/+5V/+12V

OSD Key — Power, Menu (/OK), Exit (/Back), Up, Down

OSD Language — English

Board Dimension — 190 x 105 mm

Dimension — 610 x 422 x 100 mm

Weight — TBD

Tocuh Screen

Touch Screen — 5-Wire Resistive Touch

Active Area — 519.4 (H) x 325 (V) mm

Touch Interface — USB

Touch Glass — AG Strengthen Glass

EMI Mesh — Yes

Optical Bonding — Yes

Touch Drives — Support Windows, Linux, Mac, etc.
