Supported Resolution

Up to 2560 x 1600 @60Hz Panel

Input Interface (Border Line)

1x VGA

1x DVI

2x HDMI

1x Audio

Input Interface (On-Board Housing)

Backlight, STB (5V, 1amp), Light Sensor, Key + IR, RS232/485 (Reserved Optional), Audio, Display Port (Reserved, Optional)

Output Interface

1x LVDS (40 Pins)

Others

1x USB-A (By-Pass)

Audio

10W+10W @ 8Ω Class-D stereo Audio Amplifier

Power Input

DC+12V/ 24V (9-26 Available)

Max. Current: 3amp; Quiescent Current <50mA

Backlight Power Output

**By-Pass from DC Jack Power Input

(Needs to Make Sure the Power Input = Backlight Power Required)

Backlight Max Current

6amp

LVDS Power Selection

DC+3.3V/+5V/+12V

OSD Key

Power, Menu (/OK), Exit (/Back), Up, Down, +, -

OSD Language

English

Board Dimension

190 x 105 mm
