Operation system

Linux

Chipset solution

Ambaralla

Sensor

Sony IMX335

Night mode

Low light less than 0.1 lux for colorful video recording

Display

LCD segment screen to tell storage capacity and battery lfie

Buttons

The left side is the power switch and confirmation button. Press and

hold for 3 seconds to turn the machine on and off. It is the

confirmation button when operating the menu.

The right side is the selection and flashlight switch. The selection

button moves the cursor when operating the menu. During the video

recording, short press to turn on and off the LED flashlight

Battery

Rechangeable Ultrasonic lithium battery

Battery type

Lithium battery and rechargable

Battery life

More than 8 hours for 1080P@30fps at full charging

Mic

Built-in AGC, located at the rear of the machine, close to the

waterproof cover. The opening size is the same as the diameter of the

microphone head to ensure the voice quality

RTC clock

The rechargeable lithium battery provides continuous power to the

RTC, ensuring that the time will not be lost if the power is cut off for a

short period of time.

Alerts

Beep and vibration as the notification (e.g. switching on the deive /

low battery / SD card faulty)

Indicators

LED indicator to show the battery status

Camera lens material

Temper glass anti-scratched

LED flash light

During recording, press the button to turn on/off the LED flashlight

Storage

TF card supports from 32GB to 512GB

Interface

TYPE-C USB, TF SD Card, RJ 45, DC Power

Mounted

Attached top of the helmet

IP Rating

IP68

Encryption

AES-XTS-256

Software

Encryption

AES256

Password protection

5-digit administrator password / 8-digit playback password

Video codec

H.264 or H.265, file format MOV. Loop recording, no missing seconds

(<0.05 seconds).

Video resolution

1080P / 720P

FPS

30, 15, 10, 6, 5, 3, 2, 1 fps(60Hz) or 25, 12, 8, 5, 1 fps(50Hz)

Bitrate

1~20M bit (6M bit)

Bitrate Control

VRB, CBR

Stream Options

Main stream: RTSP, Sub stream: H.264/MJPEG

Network Protocol

TCP/IP, UDP/IP, RTP, RTSP, RTCP, NTP, HTTP, DHCP, FTP, SMTP, DNS,

DDNS, ONVIF

Stream Viewer

Supports viewing in a web browser.

Wi-Fi

Optional

GPS

Standard

Frame per second

30

EIS

Supports

White balance

Auto

Gain

Auto

Brightness

Auto

Notification

When there is no TF card or the TF card is damaged, the buzzer will sound

LCD display language

English
