LCD Panel

LCD Size — 8 inch IPS

Backlight — LED

Resolution — 1920 x 1200

Brightness — 550 nits

Touch Glass — 5-Point Capacitive Multi Touch Screen, 7H Tempered Glass, G+G

Camera —  Front 5.0MP; Rear 13.0MP with AF & Flashlight

System

CPU — Qualcomm Dragonwing QCM6490

Arm® Cortex®-V8 Processor

Octa-Core Kryo 670 CPU, Up to 2.7GHz

Memory — 8GB

Storage — 128GB

Interfaces —

• 1x USB-A 3.0

• 1x USB-C 3.0 (Data & Charging)

• 1x HDMI mini 2.0

• 2x Nano SIM Card Slot or 1x Nano SIM Card Slot + 1x Micro SD Card Slot (up to 512GB)

• 1x 3.5mm Earphone Jack

• 1x 12 PIN Pogo Pin

Buttons —

• Power (Yellow)

• Volume + Key

• Volume - Key

• P1 Key (HOME Key)

• Function Key (Barcode Scanning) #1

Connectivity —

Wi-Fi 6E& DBS, IEEE 802.11a/ b/ g/ n/ ac/ ax, Wi-Fi 2 × 2 MU-MIMO Bluetooth 5.2

• 5G:SA/ NSA: n1/ 3/ 5/ 7/ 8/ 20/ 28/ 38/ 40/ 41/ 77/ 78/79

• 4G: B1/ 2/ 3/ 4/ 5/ 7/ 8/ 12/ 17/ 18/ 19/ 20/ 26/ 28/ 32/ 34/ 38/ 39/ 40/ 41/ 42

• 3G: B1/ 2/ 4/ 5/ 6/ 8/ 19

• 2G: B2/ 3/ 5/ 8

GNSS — Supports GPS/GLONASS/BDS; Dual-frequency L1 + L5

NFC — Built-in, 13.56MHz, Supports 14443A/14443B/15693 of ISO/IEC

Card Reading Distance: 0-4cm

2D Scanner (Optional) —

• Optical Resolution: 5mil

• Scanning Speed: 50 times/s

Speaker — 2x Built in 8Ω/1W Waterproof Speaker

Microphone — Sensitivity: -42db, Output Impedance 2.2kΩ

OS — Android 14

Battery — 10000mAh, Removable Polymer Lithium-ion Battery

System Level Customization — Available Based on Customization of Android at the Framework and System Level #2

Power — DC5V/4amp or PD 18W

Mechanical

Colour — Black-Grey

Dimension — 237 x 155.9 x 21 mm (W x L x H)

Material — Polycarbonate (PC) & Thermoplastic Polyurethane (TPU)

#1: Optional Function Keys are provided a customized basis that would need definition from user. Otherwise, F1-F4

will be defined as keyboard F1-F4 accordingly (If 4x function keys are needed condition)

#2: Customization will be separately quoted based on the request and functions required at the framework and system level. For example, power management, volume, watchdog, Google service, etc
