LCD Panel

LCD Size — 8 inch IPS

Backlight — LED

Resolution — 1920 x 1200

Brightness — 550 nits

Touch Glass — 5-Point Capacitive Multi Touch Screen, Strengthen Glass

Camera — Front 5.0MP; Rear 8.0MP

System

CPU — Intel® Processor N100, 6M Cache, Up to 3.40 GHz

Memory — 8GB

Storage — 128GB

Interfaces —

• 1x USB-A 3.0

• 1x USB-C 3.0

• 1x HDMI mini 2.0

• 1x SIM Card Slot

• 1x SD Card

• 1x 3.5mm Earphone Jack

Buttons —

• 4x Function Keys #1

• 1x Power Button

Connectivity —

• WIFI6 802.11(a/b/g/n/acR2/ax 1x1) Frequency 2.4G+5.8G Dual-Band  Bluetooth 5.2

• 4G: LTE-FDD: B1/B3/B5/B7/B8/B20/B28; LTE-TDD B38/B40/B41

GNSS — GPS + Glonass

Support System — Linux Ubuntu 22.04.4

Battery — 5000mAh, Removable Polymer Lithium-ion Battery

Power Management — Optional customized third-party developed, non-system-based

software required for power and performance management. #2

Power — DC12V

Mechanical

Colour — Black-Grey

Dimension — 237 x 155.9 x 21 mm (W x L x H)

Material — Polycarbonate (PC) & Thermoplastic Polyurethane (TPU)

#1: Function Keys are provided a customized basis that would need definition from user. Otherwise, F1-F4 will be defined as keyboard F1-F4 accordingly.

#2: ACT can assist in introducing third-party software developers for this solution.
