LCD Panel

LCD Panel Size — 21.5-inch TFT LCD

Backlight — LED

Resolution — 1920 x 1080

No. of Colors — 16.7M

View Angle —  ± 89° (H), ±89° (V)

Luminance — 300 nits (after Bonding)

Contrast Ratio —  1000:1

Pixel Pitch — 0.24795 x 0.24795mm

Aspect Ratio — 16:9

LCD Panel Life Time — 50,000 hrs.

Interface — LVDS

Response Time — 115ms (Tr+Tf)

Active Area — 476.064(W) x 267.786(H) mm

Touch Glass

EMI Mesh — Yes

Optical Bonding — Yes

Cover Glass — Strengthen Glass

Glass Surface Hardness — >5H

AD Board (IAD-M121)

Power Input — 12VDC/ 24VDC (Power Input Bypass for Backlight)

Input Sources —  2x HDMI, 1x VGA, 1x DVIVGA, HDMI, Audio Input

OSD —  Multi Language OSD Menu; Buttons: Power ON/OFF, Menu, Source, Adjust -, Adjust +
