LCD Panel
LCD Panel Size — 15-inch TFT LCD
Backlight — LED
Resolution — 1024 x 768
Interface — LVDS
View Angle — ± 88° (H), ±88° (V)
Luminance — 700 nits (after Bonding)
Contrast Ratio — 2500:1
Aspect Ratio — 4:3
Response Time — 13 (Tr+Tf) ms
No. of Colors — 16.7 Million (8 bit/colour)
Active Area — 304.1 x 228.1 mm
Pixel Pitch — 0.297 (H) x 0.297 (V)
LED Life Time — 50,000 hrs
Touch Screen
Touch Type — 5-Wire Resistive Touch
Viewable Area — 311.1 x 235.1 mm
Active Area — 307.1 x 231.1 mm
Touch Interface — USB
Touch Glass — AR/AG Strengthen Glass
EMI Mesh — Yes
Optical Bonding — Yes
Touch Drivers — Support Windows, Linux, Mac, etc.
Operation Temperature
-20°C to +70°C
Storage Temperature
-40°C to +70°C
Humidity
Ta ≦ 40°C, 90% RH, Non-Condensing
Shock
Design to Meet MIL-STD-810G
Vibration
Design to Meet MIL-STD-810G
EMI/EMC
Design to Meet MIL-STD-461E/F
MIC-D1506
15” Resistive Touch LCD Module with EMI Mesh & Optical Bonding & AD Board Kits
