LCD Size

24” TFT Active Matrix LCD

Contrast Ratio (Typical)

1200:1

Resolution

3840 x 2160

Brightness

250 nits (After Bonding)

No. of Color

1.07b

Response Time

15ms

Active Area

527.04 x 296.46 mm

Pixel Pitch

0.1369 (H) x 0.1369(V)

LED Life Time

30,000 Hrs

Video Interface

DVI x1 (MIL-DTL-D38999-26pin)

HDMI 2.0 x1 (MIL-DTL-D38999-19pin)

DP 1.2 x1 (MIL-DTL-D38999-20pin)

Dimming Ratio

500:1

Touch

Capacitive Multi-Touch

Touch Interface

USB x1 (MIL-DTL-D38999-5pin)

Protection

IP65 Front Bezel

Power Input

28 VDC (Design to Meet MIL-STD-704F for Airborne)

Power Consumption

100W

Other

Optical Bonding with EMI Mesh (SE ≥ 60 dB)

Mounting

Console Mounting

Form Factor

650 x 437 x 76 mm (TBD)

Weight

≧13 Kg (TBD)

Material

Aluminum 6061 (Anodizing)
