SLM-MN050K-E
- 5 TFT LCD Panel
- Operating Temperature: -20°C To +70°C
- Storage Temperature: -30°C To +80°C
- Optical Bonding: EMI Mesh With Optical Bonding
- LED Life Time: 50,000 Hours (Min)
- EMI/EMC Is Designed to Meet ML-STD-461E/F
- Shock Is Designed to Meet MIL-STD-810D
- Vibration Is Designed to Meet MIL-STD-810E
5" No Touch Military LCD Kit
LCD Panel Size
5 TFT
Backlight
LED, Normally White
Resolution
800 x 480
View Direction
12 O’clock
Gray Scale Inversion Direction
6 O’clock
Luminance
400 Cd/M² (After Bonding)
Contrast Ratio
500:1
Aspect Ratio
5:3
Response Time
25 (Tr+Tf)
TFT Interface
HDMI
Active Area
108 x 64.8mm
Pixel Pitch
0.135(H) x 0.135(V)
LED Life Time
50,000 Hr
Expansion
Raspberry Pi CM4 Compatible
Operating Temperature
-20°C To +70°C
Storage Temperature
-30°C To +80°C
Humidity
95% RH, @ 70°C Non-Condensing
EMI/EMC
The LCD Kit Is Designed to Meet ML-STD-461E/F for a Whole Display Unit (Note)
Shock
The LCD Kit Is Designed to Meet MIL-STD-810D for a Whole Display Unit (Note)
Vibration
The LCD Kit Is Designed to Meet MIL-STD-810D for a Whole Display Unit (Note)
Altitude Above Sea Level
0～9144 M (30,000 Feet) (Note)
Net Weight
Approx. 50 G
(The Actual Weight Is Determined by the Final Design and Application)
Gross Weight
Approx. 170 G
(The Actual Weight Is Determined by the Final Design and Application)
*Note: This LCD Kit Provides Basic Requirements to Be Assembled for Meeting Above Certification While the Final Validation on the Finished Product Would Still Depend on the Final Design.
SLM-MN050K-E
5 Inch No Touch Military LCD Kit
