LCD Panel

LCD Panel Size — 24 Inch TFT

Backlight — LED

Resolution — 1920 x 1200

Interface — LVDS

View Angle — ±89° (H), ±89° (V)

Luminance — 450 nits (After Bonding)

Contrast Ratio — 1000:1

Aspect Ratio — 16:10

Response Time — 14 (Tr+Tf) ms

No. of Colors — 16.7 Million (8 bit/Color)

Active Area — 518.4 (H) x 324 (V) mm

Pixel Pitch — 0.27 (H) x 0.27 (V) mm

LED Life Time — 50,000 Hrs

Touch Screen

Touch Type — 5-Wire Resistive Touch

Active Area — 519.4 (H) x 325 (V) mm

Touch Interface — USB

Touch Glass — AG Strengthened Glass

EMI Mesh — Yes

Optical Bonding — Yes

Touch Drivers — Support Windows, Linux, Mac, Etc.

Accessories

Boards — USB Touch Control Board

Cables — LVDS Cable, Touch Control Board Cable, LED Backlight Cable

Optical Bonding — Yes

Touch Drivers — Support Windows, Linux, Mac, Etc.
