Processor

Intel Celeron J1900

Chipset

Intel Bay Trail SOC

Memory

1 x SO-DIMM DDR3L 1333 MHz, up to 8GB (Single Slot),

Compatible with 1600 MHz

Graphics

Integrated Intel ® HD Graphics

I/O Interfaces

1 x VGA, 1 x HDMI

Internal Headers: 1 x LVDS, 1 x HDMI

Supports Dual-Display and Triple-Display Simultaneous/Asynchronous Output (Clone, Extended)

Resolution

1920 x 1080 @ 60 Hz

USB

1 x USB 3.0, 3 x USB 2.0, 4 x USB 2.0

Audio

Realtek ALC897 + NS4258, Amplifier Supports 5.2w @ 2Ω, 3.2W @ 4Ω

LAN

RTL 8111H Gigabit Ethernet

Storage

1 x mSATA, Internal Port: 1 x SATA 2.0

PS/2

Keyboard/Mouse, Internal Header: 1 x PS/2

I/O Chipset

IT8786e-I

Expansion Slot

1 x Mini PCIe (Supports WIFI + BT /4G Modules)

Other I/O Ports

1 x DC Jack, 1 x RJ45, 1 X Line-Out (3.5mm Audio Output), 1 x Mic-In (3.5 mm Microphone Input)

Operating System

Windows 7 / 8 / 8.1 / 10

Form Factor

Mini ITX 170 x 170mm

Power Support

Recommended 12V / 4A or above

CPU Specification

CPU Series — Intel Celeron

CPU Model — J1900

Base Frequency — 1.99 GHz

Burst Frequency — 2.41 GHz

Cores — 4

Threads — 4

CPU Power (TDP) — 10W

Motherboard Full Load Power — Approx. 30W
