CPU

Integrated Intel® CoreTM 12th/13th Generation - U/-P series Processor, TDP 15W, UEFI BIOS

Memory

2x DDR5 SO-DIMM, Total Maximum 64GB

Storage

1x M.2 M-Key 2280 (PCIe 3.0 x 2 and SATA 3.0, Hardware Option)

Display

1x HDMI 2.0

1x Mini DP

1x Type-C (DP + USB3.0)

I/O

DC Phoenix Terminal

2x LAN

1x HDMI

1x Mini DP

1x Type-C

7x USB

1x DB9 RS422/485 (COM3, BIOS)

3x DB9 RS232 (COM1/2/4) Switch Button

4x ANT Holes

8 bit GPIO

1x Audio Two-in-One

Expansion

External TPM2.0 Optional

1x E-Key (PCIe + USB 2.0, WIFI/BT)

1x B-Key (USB3.0 + USB 2.0 , 4G/5G)

Power Supply

DC 9-36V, 120W

OS

Windows 10 IoT

Material and Color

Aluminium Profile, Iron Grey, Fanless Design

Installation

Desktop Foot Pad Type (Default), 35mm Industrial Rail Type, Wall-Mounted

Size

174 x 129 x 86 mm (without Bracket)

Gross Weight

About 4 Kg
