CPU

Intel® Core™ i9 Processor 14900, 36M Cache, up to 5.80 GHz or Same Generation Compliance

Memory

4x DDR5 DIMM Sockets Supporting up to 128 GB

Pre-Mount: 32GB

Storage

1x M.2 Connector (Socket 3, M Key, Type 22110/2280 PCIe 4.0 x4/x2 SSD Support) (M2P_SB)

4x SATA 6Gb/s Connectors

Pre-Mount: 1x 4TB SSD, 1x 2TB SSD (3.5” SATA)

Graphics

Intel® UHD Graphics 770

Display

1x HDMI

1x DP

(On Board; without Graphic Card)

Ethernet

Realtek® 2.5GbE LAN Chip (2.5 Gbps/1 Gbps/100 Mbps)

Audio

Realtek® Audio CODEC, High Definition Audio

2/4/5.1/7.1-Channel

Other I/O

1x USB-C (Includes USB, DP & PD Functions, Support Max. 9V 3amp)

4x USB3.0 (1x Gen2, 3x Gen1)

4x USB2.0/1.1

1x COM

1x Mic In & 1x Line Out

WIFI/GPS

On Board Intel® Wi-Fi 6E AX211

Support WIFI a, b, g, n, ac, ax 2.5/5/6 GHz, BT 5.3

Expansion

2x PCIe 4.0 x16

GeForce RTX 3060 VENTUS 2X 12G OC (12GB GDDR6)

Interface: 3x DP; 1x HDMI

Power Input

100-240VAC

Support

Windows 10/11, Linux (Separately Quoted)

Material

Metal

Dimension

455 x 427 x 172mm (Approx.) or Other 4U Chassis
