CPU

Intel® Whiskey Lake, Come Lake or CoffeLake, 8th /10th Celeron or Pentium,

Core® i3/i5/i7 CPUs

Memory

1x SO-DIMM Slot, Supports Single-Channel 2400MHz DDR4 Memory,  Maximum Support Up to 32GB

Graphics

Integrated Intel® HD Graphics 620

Display

1x HDMI, Support 4096x2304@24Hz

1 x LVDS or eDP(Default LVDS)

Ethernet

5x Intel WGI2101AT Gigabit Network, Supports Wake-On-LAN/PXE, LAN2~LAN5

Support PoE

Storage

1x SATA 3.0

1x mSATA3.0Slot

Audio

 ALC897 7.1 Channel High-Definition Audio Controller, Supports MIC In/Line-Out, Amplifier 4Ω/3W Dual-Channel

Expansion Slot

 1x Mini-PCIe Slot, Supports WIFI/4G module

Back Panel I/O

 1x HDMI

2x USB 3.0

5x RJ-45 Gigabit Network

1x 9~36V DC Power Input

1x 9~36V DC Power Input (Phoenix Connector)

Internal I/O

1x 4 Pin Power Connector, Supports 9~36V DC Input/Output

1x eDPInterface 2*15Pin, Default LVDS

1x LVDS Interface 2*15Pin, Supports Dual-Channel 24bit

1x Backlight Power Interface 1*6Pin

4x USB 2.0 Pin Header Interfaces 2*5Pin

1x Amplifier Port 1*4Pin

2x RS232 Serial Ports, Support RS485/RS422

1x Front Audio Interface 2*5Pin

1x HDD Power Connector

1x Front Panel Switch and LED Indicator Interface 2*5Pin

Fan Connector

1x 4 Pin CPU Smart Fan Connector

1x 4 Pin System Smart Fan Connector

GPIO

Supports 4 GPIO Inputs/Outputs

BIOS

64Mb Flash ROM

Watchdog

Supports Hardware Reset Function (256 Levels, 0~255 Seconds)

Support OS

Windows 7/10/Linux

Power Supply

Supports 9~36V DC Power Supply
