Performance

OS — Windows 11 Pro

CPU — Intel I5-1235U, 10 Cores, 12 Threads/Basic Frequency 1.3GHz, Turbo 4.4GHz /Power Consumption 15W

GPU — Intel® Iris® Xe Graphics 80EU

Memory & Storage

• RAM: 8GB/16GB (Maximum 64GB)
• ROM: 128GB/256GB/512GB

Display — 10.1” ; 1200*1920; 450 nits

Touch — 10-Point Capacitive Touch

Camera (Optional) — Front 5MP, Rear 8MP

Bluetooth (Optional) — 5.2 Version

WIFI (Optional) — 802.11a/b/g/n/ac/ax Wireless Internet Wireless AP (Mobile AP) 2.4G, 5G

MIC (Optional)

• Sensitivity: -32±2d
• Output Impedance: 2.2kΩx1

Battery — 6000mAh, 7.6V Lithium Battery (45.6Wh) DC4.0, 12V DC Input

Bands

• FDD_LTE: B1/B2/B3/B4/B5/B7/B8/B28 TDD_LTE: B40
• WCDMA: B1/B2/B4/B5/B8
• GSM: B2/B3/B5/B8

Navigation — GPS, GLONASS

NFC — 13.56 MHz, Distance 1-3cm

Speaker — 8Ω 1.5 Watt

Sensor

• Light Sensor
• Acceleration Sensor
• G-Sensor

1D/2D Barcode — Optional

UHF RFID — Optional

Brightness — 1000 nits

RAM — 8GB

ROM — 256GB

Camera

• Front Camera: 8MP Pixel
• Rear Camera: 32MP Pixel, Auto-Focusing

Battery — 12000mAh, 33W Fast Charging

NFC — Yes

Work Time

• Operation Time: 15 Hours
• Standby: About 15 Days

Button

• 1 x Power On/Off, 1 x Volume +/-
• 1 x Programmable Smart Key, 1 x Broadcast Key

Compass — Support

AC Power — 110~240v 11V 3A

Wireless

• WIFI (2.4G/5G) / WIFI6
• Bluetooth: BT5.2
• GPS, GLONASS, Galileo

Sensor — Gravity Sensor, Light Sensor, Range Sensor, Gyroscope Sensor

I/O Port

• USB Type C
• Supports OTG

Others

• TF Card: Supports up to 512GB Micro SD
• SIM Card: Double SIM (Nano)

Communication

2G — GSM850/900/1800/1900

3G — 850/900/1700/1900/2100(Band1、2、4、5、6、8、19)

4G

• FDD-LTE: Band1/2/3/4/5/7/8/12/17/18/19/20/25/26/28AB/66
• TTD-LTE:B34/38/39/40/41

5G — N1/N3/N7/N28/N38/N41/N77/N78/N79

Physical Characteristics

Form Factor —  217 x 129.3 x 16.2 mm

Weights — 643g
