CPU Processor

MTK MT6789 (Octa Core, Octa Threads, 2.2GHz)

GPU

Mali-G57 MC2

Memory & Storage

8GB / 256GB

Display

LCD 8-inch

Resolution

800 x 1280, 1000 nits

Touch

10-Point Touch, Support Glove Touch & Wet Touch

Camera

Front Camera: 5MP

Rear Camera: 13MP (with Flash Light)

Battery

7800 mAh 3.8V

(Can Customize to 10000 mAh with Fast Charging)

WWAN

4G LTE, 3G WCDMA, GSM

GPS

BDS, GPS, GLONASS

WIFI

802.11a/b/g/n/ac Wireless Internet  Wireless AP

(Mobile AP) 2.4G, 5G

Bluetooth

5.0 Version

NFC

13.56 MHz, Distance: 1-3cm

MIC

Sensitivity: -32±2d

Output Impedance: 2.2kΩx1

Speaker

8Ω 1.5 Watt

Sensor

1. Light Sensor

2. Magnetic Sensor

3. Pressure Sensor

4. G-Sensor

5. Distance Sensor

6. Acceleration Sensor

7. Gyroscope

8. Motor

1D/2D Barcode

Optional

UHF RFID

M-500 / M-301 (Optional)

Fingerprint

Optional

Interface (In/Out Port)

1. 1 x Type-C ,OTG

2. 1 x SIM Card Slot

3. 1 x TF Card Slot

4. 1 x Earphone

5. 1 x DC; 3.5 x 15mm

6. 2 x USB 2.0

7. 1 x RS232 (Mini-USB)

Button

1 x Volume +/-, 1 x Power, 1 x Barcode Scan(F)

Dimension

234 x 144 x 16.8 mm

Weight

630 ± 20g

Accessories

Standard: DC Charger (5V 3A), Wrist Strap, Screw

Additional: Hand Strap + Shoulder Strap
