LCD Size

6.9 inch

Backlight

8-LED Backlight

Resolution

280 × 1424

Interface

MIPI

Viewing Angle

85° Typical (Up/Down/Left/Right)

Brightness

300 cd/m² Typical; 250 cd/m² Minimum

Contrast Ratio

400:1 Typical; 350:1 Minimum

Aspect Ratio

1:5.09

Response Time

35 ms Maximum

Display Colors

16.7 million Colors

Pixel Pitch

0.12 × 0.12 mm

LED Lifetime

25,000 Hours

Power Consumption

0.6 W Typical

Touch Interface

I²C

Touch Type

Capacitive

System Board Characteristics

SoC

Rockchip RK3566

Memory

2GB RAM + 16GB Storage

Resolution

280 × 1424 for Display Configuration

I/O Port

USB 2.0 × 3, USB OTG × 1, TTL UART ×2, GPIO, ADC and 10/100Mbps   Ethernet

Output LCD Interface

40-pin MIPI

OS

RK3566 Quad-Core Processor 1.8GHz
