System

CPU — Rockcihip Quad Core Cortex – A55 up to 2.0GHz

Memory — 4GB

Storage — 32GB

Interface —

2x USB 2.0

Type C (OTG)

1 x HDMI out

1 X RJ45 10M/100M

DC Power Jack (Input)

1x 3.5mm Audio Jack

OS — Android 11

WIFI — Support WIFI 6

Bluetooth — Support Bluetooth 5.4

Speaker — Built-In 2W Speaker

Mic — 1*Digital Mic

Power — Adapter 12V3A

LCD Panel

Touch Type — 14.1" IPS LCD Panel

Backlight — LED Backlight 300cd m2

Resolution — 1920 x 1080

Touch Screen

Touch Type — 10-Point, G+G

Housing

Glass Thickness — 1920 x 1080

Cover Glass Surface — AG

IK Protection — IK7

Printing Color — RAL9004 (Black)

Strengthening — Thermally Strengthened

Touch Controller — EXC81W60

Touch Interface — USB

Touch Resolution RX — 39

Touch Resolution TX — 24

Certification

Certification — CE, FCC

Chassis

Case Design — Rubber Frame Sealing

IP Protection — IP65 Front / IP40 Back

Case Color — RAL9004 (Black)

Case Coating — Powder Coating

Case Material — Aluminum

Case Size — 278.0 (L) x 203.6 (W) x 43.3(H) mm

Cut-Out for Clamp Supports — 264.0 (L) x 196.0 (H)

Max. Wall Thickness for Clamp Supports — 5.0

Amount of Clamps Required — 4

Mounting — VESA 100 x 100

Power

Power Indicator — Green LED

Working Power — 12V

Power Consumption — 8.5W

Stand-by Consumption [Android / Ubuntu] —  <1W / <3W

Weight

Net Weight  — ~2.00 kg est.
