Touch Panel

Touch Type — Projected Capacitive 10-Point Multi-Touch

Printing Type — Organic

Glass Thickness — 1920 x 1080

Cover Glass Surface — AG

IK Protection — IK7

Printing Color — RAL9004 (Black)

Strengthening — Thermally Strengthened

Touch Controller — EXC81W60

Touch Interface — USB

Touch Resolution RX — 39

Touch Resolution TX — 24

Certification

Certification — CE, FCC

Chassis

Case Design — Rubber Frame Sealing

IP Protection — IP65 Front / IP40 Back

Case Color — RAL9004 (Black)

Case Coating — Powder Coating

Case Material — Aluminum

Case Size — 278.0 (L) x 203.6 (W) x 43.3(H) mm

Cut-Out for Clamp Supports — 264.0 (L) x 196.0 (H)

Max. Wall Thickness for Clamp Supports — 5.0

Amount of Clamps Required — 4

Mounting — VESA 100 x 100

Power

Power Indicator — Green LED

Working Power — 12V

Power Consumption — 8.5W

Stand-by Consumption [Android / Ubuntu] —  <1W / <3W

Weight

Net Weight  — ~2.00 kg est.
