CPU

Intel SkyLake-U or Kaby Lake-U Celeron, Pentium, Core® I3/I5/I7 CPUs

Memory

Dual-Channel 2133MHz DDR4/1.2V Laptop Memory, Up to 16GB

Graphics

Integrated Intel® HD Graphics 540/610/620/650

(Depending on the Specific CPU Model)

1x VGA or DP Interface (Supports 4K 60Hz)

1x HDMI Interface

1x LVDS or eDP Interface (Default is LVDS)

Supports Sync/Async Display with VGA or DP, HDMI, LVDS, or Edp

Ethernet

1x Realtek RTL8111H Gigabit Network Card (Optional 2 Network Ports), Supports Wake-On-LAN/PXE

Storage

2x SATA 3.0 Interfaces

1x M.2 Key-M 2280/2242 Slot

Audio

ALC897 7.1-Channel High-Definition Audio Controller, Supports MIC/Line-out, Amplifier (2 ohms, 5W Dual-Channel)

Expansion Slot

1x Mini-PCIe Slot (Supports Both Half and Full-Size Cards)

Supports WiFi/4G Modules (Mini-PCIe Slot Can Also be Configured as mSATA)

1x M.2 Key-E Slot, Supports WiFi Modules

Back Panel I/O

1x HDMI Display Interface

1x VGA Display Interface (or DP Interface Supporting 4K 60Hz, VGA is the Default)

2x USB 2.0 Interfaces (USB 2.0 and RJ45 are Mutually Exclusive)

2x USB 3.0 Interfaces

1x RJ-45 Gigabit Network Interface (LAN2 and USB 2.0 are Mutually Exclusive)

1x Line-out Interface (Green)

1x MIC Interface (Red)

1x 12V DC Power Input

Internal I/O

1x JHDMI Interface, 2* 8Pin (Optional)

1x JVGA Interface

1* 12Pin (Shares the Same Signal as DB15)

1x LVDS Interface, 2* 15Pin

Supports Dual-Channel 24bit (Mutually Exclusive with eDP, LVDS is the Default)

1x Screen Backlight Power Interface, 1* 6Pin

1x eDP Interface, 2* 15Pin (Mutually Exclusive with LVDS, Optional)

4x USB 2.0 Interfaces, 2* 5Pin (When Dual Networks are Supported, Up to 6 USB 2.0 Interfaces are Available)

1x Front Audio Interface, 2* 5 Pin

1x Amplifier Interface, 1* 4Pin

6x COM Interfaces (*Note 1)

1x LPT Interface

1x PS2 Interface, 1* 6Pin

1x Hard Disk Power Interface, 1* 4Pin

1x 4Pin ATX Power Interface

1x Front Panel Switch and LED Indicator Interface, 2* 5Pin

Fan Connector

1* 4Pin CPU Smart Fan Interface

1* 4Pin System Smart Fan Interface

GPIO

Supports 4 GPIO Inputs/Outputs

BIOS

64Mb Flash ROM

Watchdog

Supports Hardware Reset Function (256 Levels, 0~255 Seconds)

Support OS

Windows 7/Windows 10/Linux

Power Supply

Supports DC 12~19V

*Note 1: (COM2/COM3 Support RS485, COM1/2 Pin9 with Power, Optionally Used as 2 Serial Ports)
