Technology

Standard  —

• IEEE 802.3u 100BaseTX
• IEEE 802.3ab 1000BaseT
• IEEE 802.3ae 10GBase over Fiber
• IEEE 802.3x Flow Control
• IEEE 802.3ad/802.1AX LACP IEEE 802.1D Spanning Tree Protocol
• IEEE 802.1w Rapid STP
• IEEE 802.1s Multiple STP ITU-T G.8032 / Y.1344 ERPS
• IEEE 802.1Q VLAN Tagging
• IEEE 802.1ad Stacked VLANs
• IEEE 802.1p Class of Service
• IEEE 802.1X Network Authentication
• IEEE 802.1AB LLDP IEEE 1588 PTP

Processing Type  — Store and Forward

Switch Properties

Switch Fabric — 640Gbps

Priority Queues — 8 Queues

Jumbo Frames — 12288 byte

MAC Table Size — 32K

Packet Buffer — 32M bits

VLAN Table Size — 4094

IGMP Group — 1023

ACL Group — 4096

VLAN IP Entries — 32

Routing Entries (IPv4/IPv6) — 16K/8K Host, 16K/16K LPM

Software Feature

Network Redundancy — RSTP, MSTP, G.8032 ERPSv2, Port Trunking with LACP

Security — 802.1X, RADIUS, TACACS+, SSL, SSH

Management — IPv4, IPv6, Web, Telnet, Serial Console, CLI, SNMP v1/v2c/v3, uPnP

Diagnostics —RMON, SNMP Inform/Trap, Syslog, SMTP, Port Mirroring, LLDP, DDM

Configuration — DHCP Server/Client, Relay Option 82, TFTP, USB

Filter — 802.1Q VLAN, Q-in-Q, IGMP Snooping v1/v2/v3, IGMP Querier,

Independent Vlan Learning

Time Sync. — NTP, IEEE1588v2 OC (Software Timestamp), BC (Software Timestamp),

TC (Hardware Timestamp)

QoS — CoS, DSCP, WRR/SPQ Queuing, Storm Protection

L3 Switching — Static Routing, RIP v1/v2, RIPng, OSPF v2, OSPF v3, VRRP v2, ECMP, PIM-SM/SSM

Interface

RJ45 Port — 24x 100M/1G/2.5G/5G/10GT(x), Auto Negotiation Speed Duplex Mode,

Auto MDI/MDI-X

Fiber Port — 8x 1G/10G SFP+ Slot

LED Indicators — Per Unit: PWR, Status, FAN Ports: Link/Active with Highest Speed

(Green), Low Speed (Amber)

Button — Multiple Functions Reset Button

Serial Console — 1x RS232 in RJ45 Connector with Console Cable, 115.2Kbps, 8N1

Storage — 1x USB 2.0 Storage for Firmware Update, Configuration Backup, Restore,

Boot Up and Syslog

Power Requirements

Operation Voltage — 100– 240VAC

Connection — 1x AC Socket

Power Consumption — 46W

Protection — Overload Current Protected

Mechanical Construction

Enclosure — Aluminum/ Steel

Protection Class — IP30

Form Factor — 440 x 44 x 310mm (W x H x D)

Weight — 5.00 kg

Mounting — Rack Mounting
